“S” Series Mixers

S0v2 Radio Broadcast Mixer

The S0v2 is a high quality yet simple to operate radio broadcast mixer ideally suited to community radio stations, for educational purposes and for internet radio.

S1 Digital/Analogue Radio Broadcast Mixer

The S1 has an amazing feature set and offers a proper broadcast solution to community, educational and student radio stations that need a versatile, reliable radio broadcast mixer.

S1-RCK S1 19 inch rack mount ears, 9U

The S1-RCK rack ears are an optional accessory for rack mounting the S1 radio broadcast on-air mixer.

S2-05 Chassis Design

The S2-05, 5 channel width chassis.

S2-05-NM S2 5 Channel Mixer Chassis With No Meterbridge

S2 5 channel mixer chassis with no meterbridge

S2-10 Chassis Design

The S2-10, 10 channel width chassis.

S2-10-NM S2 10 Channel Mixer Chassis With No Meterbridge

S2 10 channel mixer chassis with no meterbridge

S2-15 Chassis Design

The S2-15, 15 channel width chassis.

S2-15-NM S2 15 Channel Mixer Chassis With No Meterbridge

S2 15 channel mixer chassis with no meterbridge

S2-20 Chassis Design

The S2-20, 20 channel width chassis.

S2-20-NM S2 20 Channel Mixer Chassis With No Meterbridge

S2 20 channel mixer chassis with no meterbridge

S2-25 Chassis Design

The S2-25, 25 channel width chassis.

S2-25-NM S2 25 Channel Mixer Chassis With No Meterbridge

S2 25 channel mixer chassis with no meterbridge

S2-30 Chassis Design

The S2-30, 30 channel width chassis.

S2-30-NM S2 30 Channel Mixer Chassis With No Meterbridge

S2 30 channel mixer chassis with no meterbridge

S2-7SS Script Space

The script space occupies an area of 7 channel widths, and is designed to hold documents or scripts for the mixer operator when desk space is at a premium.

S2-BI Bus Interlink Cable

This is used to connect two S2 chassis so that they can function as one mixer.

S2-C6SS 6 Way Stereo Source Select Channel with EQ

The 6 way stereo line source select channel has 6 balanced stereo inputs on a 25 way D-type connector selectable by a 6 way mechanical interlocking switch bank, numbered 1 - 6.

S2-CB Blank Channel

This blank channel is used to fill in areas of the mixer where you don’t require an input or output channel.

S2-CDASE S2-CDASE Dual Stereo Line Channel with EQ

The S2-CDASE dual stereo line channel has one 24-bit 96kHz AES/EBU digital input and one balanced analogue stereo input, both on Neutrik XLR connectors and is fitted with equalisation, providing 10dB cut and boost at HF (6.5kHz) and LF (100Hz).

S2-CDS S2-CDS Digital Dual Stereo Channel

The digital dual stereo channel has two 24-bit 96kHz digital inputs with an INP 1/INP 2 button switch to select between them.

S2-CDSE S2-CDSE Digital Dual Stereo Channel with EQ

The digital dual stereo channel has two 24-bit 96kHz digital inputs and is fitted with equalisation.

S2-CML Mic/Line Channel

The mic/line input channel is a mono input with a button switch to select either Mic or Mono Line.

S2-CMM Mic/Mic Channel

The mic/mic input channel is a dual mono microphone input with a button switch to select either Mic 1 or Mic 2.

S2-CSE S2-CSE Dual Stereo Line Channel with EQ

The S2-CSE dual stereo line channel with EQ has two balanced stereo inputs on Neutrik XLR connectors and is fitted with equalisation.

S2-CSGE S2-CSGE Stereo Line & Gram Channel with EQ

The S2-CSGE channel is the dual stereo line channel with an RIAA input amplifier on the second input and is fitted with equalisation, providing 10dB cut and boost at HF (6.5kHz) and LF (100Hz).

S2-CSMM Stereo Mix Minus Channel

The stereo mix-minus channel has one balanced stereo line level input and a balanced stereo mix-minus output, on XLR connectors.

S2-CT CT Telco Channel

The telco input channel controls the connection to a telephone balance unit (or hybrid).

S2-M6SS Meterbridge 6 Way Source Select Panel

The S2-M6SS meterbridge source selector panel produces a stereo analogue audio output from 6 selectable stereo analogue sources, which can be connected to a stereo input channel within the mixer, or the EXT 1 and EXT 2 monitor inputs, to provide up to 12 external monitor inputs.

S2-MB1 Meterbridge 1 Channel Blanking Plate

The S2-MB1 1 Channel Meterbridge blanking plate.

S2-MB2 Meterbridge 2 Channel Blanking Plate

The S2-MB2 2 Channel Meterbridge blanking plate.

S2-MB3 Meterbridge 3 Channel Blanking Plate

The S2-MB3 3 Channel Meterbridge blanking plate.

S2-MB4 Meterbridge 4 Channel Blanking Plate

The S2-MB4 4 Channel Meterbridge blanking plate.

S2-MB5 Meterbridge 5 Channel Blanking Plate

The S2-MB5 5 Channel Meterbridge blanking plate.

S2-ML S2-ML Meterbridge Loudspeaker Monitor Panel

The S2-ML speaker is used for monitoring PFL and reverse talkback in the control room directly from the mixer.

S2-ML53 Meterbridge LED Meter Panel

The S2-ML53 LED meter consists of 53 LEDs showing both VU and peak representation.

S2-MPH Meterbridge Phase Meter Panel

S2-MPPM Meterbridge PPM Meter Panel

MPPM panel has two fast-reading moving-coil meters with PPM-style scale.

S2-MSB1 1 Channel Meterbridge Switch Panel

The S2-MSB1 is a meterbridge panel, 1 channel wide, with 1 button which can be used for bespoke control of the S2, or for your own purposes, e.g. equipment control.

S2-MSB3 Meterbridge Switch Panel

The S2-MSB3 is a meterbridge panel, 1 channel wide, with 3 buttons which can be used for bespoke control of the S2, or for your own purposes.

S2-MT Meterbridge DualTimer Panel

Each of the dual timers can be used for timing events triggered by Timer 1, Timer 2, or the Mic fader open signal.

S2-MTB6 Meterbridge 6 Way Talkback Panel

The S2-MTB6 is used for communicating with up to 6 other locations, studios or mixers, and with the Sonifex TB-6D and TB-6R talkback intercoms.

S2-MVU Meterbridge VU Meter Panel

The S2-MVU two moving coil VU meters are configured such that a 1kHz signal, at +4dBu at the PGM output, will indicate a meter reading of 0VU.

S2-ODA S2-ODA Digital AUD Output Channel

This channel is common to every mixer and provides a digital and analogue output from the AUD mix bus.

S2-ODAF S2-ODAF Digital AUD Output Channel with Master Fader

This channel is common to every mixer and provides a digital and analogue output from the AUD mix bus. It also has a 100mm VCA output fader for production use which provides unity gain when fully open.

S2-ODP S2-ODP Digital PGM Output Channel

This channel is common to every mixer and provides a digital and analogue output from the PGM mix bus.

S2-ODPF S2-ODPF Digital PGM Output Channel with Master Fader

This channel is common to every mixer and provides a digital and analogue output from the PGM mix bus.

S2-OMC Control Room Monitor Channel

The control room monitor channel is common to every mixer and is used for monitoring various sources on the control room loudspeakers or on headphones.

S2-OMS Studio Monitor Channel

The studio monitor channel is optional and is used for the monitoring of various sources on the studio loudspeakers or studio headphones.

S2-PSU Power Supply for S2 Mixer.

1U S2 mixer PSU is pin compatible with the original 2U sized S2-PSU power supply, so can be used as a straight like-for-like swap, using the same connection cables.

S2-PSUS Dual Power Supply Switcher

The S2-PSUS is a passive power switcher which takes the power feeds from 2 x S2-PSU units and switches between them in the event of failure.
