S2-CSGE

S2-CSGE Stereo Line & Gram Channel with EQ

The S2-CSGE channel is the dual stereo line channel with an RIAA input amplifier on the second input and is fitted with equalisation, providing 10dB cut and boost at HF (6.5kHz) and LF (100Hz).

About S2-CSGE

The S2-CSGE channel is the dual stereo line channel with an RIAA input amplifier on the second input and is fitted with equalisation, providing 10dB cut and boost at HF (6.5kHz) and LF (100Hz). The EQ button places the equalisation in and out of the signal path. The button is illuminated in yellow when the EQ is active. The channel can be used to control either one of two separate timer displays. The balanced stereo line input is on Neutrik XLR connectors and the unbalanced RIAA stereo input on phonos.

The channel is used for connecting a turntable or record deck. The GRAM inputs have RIAA equalisation suitable for magnetic pick-up cartridges.

Selecting the LINE/GRAM button switches the channel input between Stereo Line and RIAA . The button is illuminated in red to indicate when Gram (RIAA) is selected. The operation of the button is inhibited when the channel is “live”.

There are separate logic remote output controls for both of the two inputs providing start/stop functions by fader, or ON button. Remotes, etc, are triggered when the fader is up and the channel ON button shows green. The start function can be configured to be either momentary (500mS) or latched for each input. The remote outputs on the 9 way D-type plug are fed from NPN opto-isolators.

Continuous momentary start can be enabled such that when the fader is up and the channel is on, each press of the ON button triggers a momentary start.

Two remote pins can also be configured for general use as either inputs, outputs, latching, or momentary and active high or low. Uses for this include channel live indication or specific channel function remote control.

The BAL/PAN control adjusts the stereo balance in the following manner : Full anti-clockwise shifts the signal to the left and increases the signal by 6dB (right channel reduces by 6dB); full clockwise shifts the signal to the right and increases the signal by 6dB (left channel reduces by 6dB).

The 100mm VCA fader provides unity gain when fully open. The channel input signal is routed to the outputs whenever the fader is open, the ON button is selected and either or both of the routing buttons are selected.

Typical Applications

Community, student, hospital and small scale radio broadcast mixer, secondary or backup on-air mixer.

Product Data

Technical Specifications

Input/Output Impedances
Gram Input Impedance:
100 kΩ nominal. MM Cartridge loading is defined externally by the user/system design.
Stereo Line Input:
> 20 kΩ electronically balanced
Input/Output Gain Range
Stereo Line Input:
Preset pot -6dB to +10dB ref 0dBu, TRIM pot ±12dB
Frequency Response
Line Inputs:
20Hz to 20kHz, - 0.5dB,+0dB
RIAA Input:
30Hz to 16kHz ±1.5dB RIAA equalised
Noise (20Hz to 20kHz)
Stereo Inputs (fader down, no routing):
-89dB ref 0dB
Stereo Inputs (fader down, one channel routed):
-89dB
Stereo Inputs (unity gain, no routing):
-89dB
Stereo Inputs (unity gain, one channel routed):
-86dB
Stereo Inputs (unity gain, two channels routed):
-83dB
Distortion
Total Harmonic Distortion:
0.015% at 1kHz, 0dB
Total Harmonic Distortion:
0.025% at 10kHz, 0dB
Crosstalk
Inter-channel:
< -90dBu
Stereo:
-90dBu at 1kHz
Equalisation
LF Shelving at 100Hz:
±7dB
HF Shelving at 6.5kHz:
±7dB
Range
Pan Range:
off/-3dB centre/off
Balance Range:
±6dB
Common Mode Rejection Ratio
Mic Input:
> 100dB at 70dB gain
Digital I/O
Sync Input Sample Rate:
30kHz - 100kHz
Output Sample Rates (Using Onboard Clock):
32kHz, 44.1kHz, 48kHz, & 96kHz
Output Sample Width:
16, 20, 24 bit (24 bit on V2 ODA/ODP)
Output
Headphone Output Load:
>45Ω, 400Ω recommended
Maximum Output (Analogue):
+26dBu balanced into 2kΩ or greater
Power
Power (S2-PSU):
Filtered IEC, switchable 115V, 230V, fused, 210W max.
Dimensions (S2-PSU):
48cm (W) x 24.3cm (D) x 8.8cm (H)
(Raw):
19” (W) x 10” (D) x 3.5” (H)
Dimensions (S2-PSU):
51cm (W) x 41.5cm (D) x 17cm (H)
(Boxed):
20” (W) x 16.3” (D) x 6.7” (H)
Weight (S2-PSU):
Nett: 6kg       Gross: 7.8kg
Weight (S2-PSU):
Nett: 13.2lbs Gross: 17lbs
Dimensions (S2-PSUS):
48cm (W) x 23cm (D) x 4.4cm (H)
(Raw):
19” (W) x 9” (D) x 1.7” (H)
Dimensions (S2-PSUS):
55cm (W) x 39.3cm (D) x 8.5cm (H)
(Boxed):
21.6” (W) x 15.5” (D) x 3.4” (H)
Weight (S2-PSUS):
Nett: 1.58kg Gross: 2kg
Weight (S2-PSUS):
Nett: 3.5lbs  Gross: 4.4lbs
