AVN-AESIO8R

8 AES3 Input, 8 AES3 Output Dual Dante® Interface, Dual PoE

The AVN-AESIO8R converts up to 8 channels of AES3 in and 8 channels of AES3 out to and from the Dante network, with full power and data redundancy.

AVN-AESIO8R

8 AES3 Input, 8 AES3 Output Dual Dante® Interface, Dual PoE

The AVN-AESIO8R audio converter and interface converts up to eight digital stereo AES3 inputs and eight digital stereo AES3 outputs to and from the Dante Audio-over-IP networking standard. Each input can accept sample rates from 32kHz to 192kHz, which will be sample rate converted to the Dante system sample rate. A valid input signal is confirmed by front panel AES3 lock LEDs for each input. All outputs follow the Dante system sample rate. Dual Ethernet ports allow the unit to operate in redundant mode, ensuring audio routing is maintained in the event of loss of link on either of the network connections. This cost effective 1U rack-mount unit offers an easy solution for AV professionals and system integrators. It is simple to configure and operate, with all set-up done via the standard Dante Controller software and power via PoE (Power Over Ethernet). All digital AES3 inputs and outputs are on high-quality Neutrik XLR connectors and there are front panel status/confidence LEDs for PoE, Link and Clock. (The AVN-AESIO8 is available with a single Ethernet port).

Product Features

  • 8 x balanced digital stereo AES3 inputs on XLR, supporting input rates of 32kHz – 192kHz.

  • Sample rate conversion on physical inputs to Dante system sample rate.

  • 8 x balanced digital stereo AES3 outputs on XLR, output rate matches Dante system sample rate.

  • 2 x RJ45 Dante connectors (1Gb/s Ethernet Port) allowing the unit to operate in redundant or switched modes.

  • PoE and Link LED status indicators for each Ethernet port.

  • Clock LED status indicator.

  • AES3 Lock LED status indicators for each input.

  • Configuration using Dante Controller.

  • AES67 operation & Dante Domain Manager compliant.

  • Powered by PoE on either (or both) Ethernet ports, offering power supply redundancy.

  • 1U 19” rack-mount form factor.

Typical Applications

The AVN-AESI08R is suited to a wide range of professional audio environments where reliable, low-latency transport between digital and networked systems is required. It is ideal for broadcast studios, live production and events, OB trucks, and fixed AV installations such as corporate, education, and hospitality spaces. It also integrates seamlessly into houses of worship and recording studios, providing flexible, high-quality connectivity between traditional digital equipment and Dante-based audio networks.

Product Category

Digital Dante Converters

Network and AoIP

AoIP Standard:Dante
Number of Channels:16 receive, 16 transmit
Number of Streams:16 receive, 16 transmit
Sample Rate:44.1kHz, 48 kHz, 88.2kHz, 96kHz, 176.4kHz or 192kHz
Format:Linear PCM, 16, 24 or 32 bit
AES67 Support:Yes
Connectivity:2 x RJ45
Speed:1Gbps or 100Mbps
Network Modes:Switched or redundant
Dante Domain Manager Ready:Yes


AES3 Input Specifications

Input Impedance:110Ω balanced
Support Input Rates:32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz and 192kHz (sample rate converted to Dante system sample rate).
Signal Level:AES3-2009 compliant
Bit Depth:Up to 24bits


AES3 Output Specifications

Output Impedance:110Ω balanced
Support Output Rates:44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz and 192kHz (set as per Dante system sample rate).
Signal Level:AES3-2009 compliant
Bit Depth:24 bits


Balanced Line Input XLR Pinout

PinFunction
1Chassis Ground
2Input Positive
3Input Negative


Balanced Line Output XLR Pinout

PinFunction
1Chassis Ground
2Output Positive
3Output Negative


PoE Power

Standard802.3af
Class0
PD Power Range0.44 W to 12.94 W
Typical PSE Power Usage7W
Max PSE Power Usage15.4 W


Equipment Type

AVN-AESIO8R:8 AES3 Input, 8 AES3 Output Dual Dante® Interface, PoE


Physical Specification

Dimensions (Raw):48cm (W) x 11cm (D) x 4.3cm (H)(1U)
Dimensions (Raw):19” (W) x 4.3” (D) x 1.7” (H)
Weight:Nett: 1.0kg Gross: 1.5kg
Weight:Nett: 2.2lbs Gross: 3.3lbs
