Telephone Hybrids
HY-03
Automatic Analogue TBU, Free Standing
The analogue HY-03 telephone hybrid is the replacement for the HY-02, which for many years has set the standard as an excellent value, high quality telephone hybrid.
About HY-03
The analogue HY-03 telephone hybrid is the replacement for the HY-02, which for many years has set the standard as an excellent value, high quality telephone hybrid. The HY-03 retains many of the features of the HY-02 and adds some additional ones. Some of the features of the HY-03 include :
-
Fully automatic – adapts to varying line conditions and has automatic signal limiting.
-
Local and remote line hold switching – calls can be remotely switched through a mixing console.
-
Momentary or permanent latching remotes can be enabled.
-
Balanced mic/line input – 10k ohm balanced input selectable for 0dBu clean feed line, or microphone level with adjustable gain.
-
Balanced output – 0dBu low impedance balanced output, with output gain adjustment.
-
Mixed output – the output can be a mix of the caller and mic/line input signals for recording both sides of the telephone conversation.
-
Integrated ring detector – automatic call answering after a pre-determined number of rings.
-
Fitted with K-break disconnect detection as standard with an option for dial-tone disconnect using the optional HY-03DTD board. The HY-03DTD board can be configured to disconnect on recognizing the dial tone used in a specific country.
-
Line limiter, bandpass filter and output noise gate with preset threshold providing low distortion crystal clear audio.
-
28dB typical line balance rejection.
-
Built in power supply with switchable 115V, or 230V, mains input.
-
BABT approval compliant with European PTT specifications.
Which Format Is Most Suitable?
The HY-03 analogue hybrids are available in three models :
-
HY-03 Single free-standing automatic analogue TBU.
-
HY-03S Single 19” rack mounted automatic analogue TBU with ringing detector.
-
HY-03T Twin 19” rack mounted automatic analogue TBU.
Typical Applications
Radio & TV station talk shows, telephony interface to the mixer.Product Data
