Passive Splitters

CM-MS3

Single 3 Way Passive Microphone Splitter

The CM-MS3 is a passive “one-to-three” splitter housed in a small but robust aluminium box.

About CM-MS3

The CM-MS3 is a passive “one-to-three” splitter housed in a small but robust aluminium box. It is designed to split a single microphone or line source to up to three destinations, using Neutrik XLR connectors. The unit uses high quality audio transformers that are capable of accepting input levels up to +18dBu, making the splitter useful in both microphone and line level splitting applications.

The CM-MS3 offers three methods of providing phantom power to a microphone connected to its input:

From the external +48VDC power connector.

From a microphone amplifier connected to output 1 (direct).

From a microphone amplifier connected to output 2 (phantom loopback).

Controlling which method is used to provide phantom power is achieved with simple push switches. It is possible to concurrently power a microphone using any two of the above methods without degrading audio performance, thus providing power supply redundancy. Ground loop hum problems can be quickly eliminated using the push switches to lift pin 1 of the output connectors (output 2 and 3 only).

Typical Applications

To share microphones between radio/TV/production studios.

Product Data

Technical Specifications

Test: Frequency Response
Conditions: Ref. -6dBu, 1kHz
Result: 10Hz - 30kHz ±0.5dB
Conditions: Source impedance = 150Ω
Result: 10Hz - 30kHz ±0.5dB
Conditions: Load impedance = 10kΩ
Result: 10Hz - 30kHz ±0.5dB
Test: Total Harmonic Distortion
Conditions: Ref. +3dBu, 50Hz
Result: 0.02%
Conditions: ource impedance = 150Ω
Result: 0.02%
Conditions: Load impedance = 10kΩ
Result: 0.02%
Test: Total Harmonic Distortion 0.1%
Conditions: Ref. 0.1%THD+N, 50Hz
Result: +13dBu
Conditions: Source impedance = 150Ω
Result: +13dBu
Conditions: Load impedance = 10kΩ
Result: +13dBu
Test: Total Harmonic Distortion 1%
Conditions: Ref. 1%THD+N, 50Hz
Result: +18dBu
Conditions: Source impedance = 150Ω
Result: +18dBu
Conditions: Load impedance = 10kΩ
Result: +18dBu
Test: Common Mode Rejection Ratio
Conditions: Ref. 20kHz
Result: >60dB
Conditions: Source impedance = 600Ω
Result: >60dB
Conditions: oad impedance = 10kΩ
Result: >60dB
Connections
Inputs:
1 x XLR 3 pin female (balanced, can be unbalanced)
Outputs:
3 x XLR 3 pin male (balanced, can be unbalanced)
DC Phantom Power Input:
+48V DC, 2.5mm socket
Equipment Type
CM-MS3
Single 3 way passive microphone splitter.
Physical Specification
Dimensions (Raw):
7.7cm (W) x 8.3cm (D) x 4.2cm (H)
Dimensions (Raw):
3.0” (W) x 3.3” (D) x 1.7” (H)
Dimensions (Boxed):
22.9cm (W) x 12.7cm (D) x 7.6cm (H)
Dimensions (Boxed):
9.0” (W) x 5.0” (D) x 3.0” (H)
Weight:
Nett: 0.30kg Gross: 0.40kg
Weight:
Nett: 0.66lbs Gross: 0.88lbs
