Passive Splitters

CM-AESB3

Single 3 Way Passive AES3ID Splitter With BNC Connectors

The CM-AESB3 is a passive β€œone-to-three” splitter housed in a small but robust aluminium box.

About CM-AESB3

The CM-AESB3 is a passive β€œone-to-three” splitter housed in a small but robust aluminium box. It is designed to split a single AES3ID digital audio source to up to three destinations, using female BNC connectors Particularly useful in a video production and broadcast environment, the CM-AESB3 splits the input signal through high quality transformers. 75Ω termination can be applied, if desired, to unconnected outputs to maintain optimum carrier parameters. The CM-AESB3 requires no power to operate, ensuring your audio remains connected from source to destination(s) without interruption from power failures.

Typical Applications

Distribution of AES3 source to 3 mixing consoles.

Product Data

Technical Specifications

CM-AESB3: Cable Drive Capability
Cumulative cable drive capability of 100m of 75Ω coaxial cable at sample rates up to and including 96kHz.
Connections
Inputs:
1 x BNC female
Outputs:
3 x BNC female
Equipment Type
CM-AESB3
3 Way passive AES3ID splitter with BNC connectors
Physical Specification
Dimensions (Raw):
7.7cm (W) x 8.3cm (D) x 4.2cm (H)
Dimensions (Raw):
3.0” (W) x 3.3” (D) x 1.7” (H)
Dimensions (Boxed):
22.9cm (W) x 12.7cm (D) x 7.6cm (H)
Dimensions (Boxed):
9.0” (W) x 5.0” (D) x 3.0” (H)
Weight:
Nett: 0.22kg Gross: 0.33kg
Weight:
Nett: 0.49lbs Gross: 0.73lbs
